Purpose-built and highly configurable, choose from a variety of available options or customize your fleet for mission-specific capabilities. Equipped with AC-powered electric drive, high-strength metal alloy frame, and adjustable bucket seats, it can move up to four passengers at a time while carrying or towing up to 1,500 pounds. Every Utilitruck is equipped with 4-wheel hydraulic brakes, an AC powered drive system, automotive lighting, controls and steering for safety and easy operation. The Utilitruck is available as an LSV which is street legal on roads with posted speed limits up to 35 MPH.
Step Height: 12.5 in.
Load Bed Height: 26 in.
Ground Clearance: 7.5 in.
| UTILITRUCK | 2X | 2XL | 4X |
|---|---|---|---|
| Vehicle Weight: | 1,500 lbs. | 1,650 lbs. | 1,750 lbs. |
| Rated Capacity: | 1,000 lbs. | 1,500 lbs. | |
| LSV Rated Capacity: | 1,000 lbs. |
1,250 lbs.
|
1,150 lbs.
|
|
Towing Capacity:
|
1,500 lbs.
|
||
Horsepower: 19 HP
Batteries: Eight, 6 volts, 232 amp hour, 122 minutes, deep cycle
Charger: On-board, micro-processor controlled, fully sealed, global, 100-230 VAC, 50/60 HZ
Controller Type: Programmable, solid state, reduced speed reverse with diagnostic LED & calibrator interface
Controller Rating: 450 amp
Motor Braking Mode: Regenerative and pedal proportional braking with top speed limiting
Directional Control: Fingertip directional control selection
LSV: Direct drive, automotive differential, 12.62:1 drive ratio
Passenger Capacity: Two with up to six (optional second-row seat and rear-facing seat)
Seating: Adjustable driver seat, fixed passenger seat, covered in marine grade vinyl with armrests
Body: Front: Rhino-Tuff™ molded polymer | Mid/Rear: Aluminum
Lighting: Dual high/low beam headlights, taillights, brake lights, self-canceling turn signals; emergency flashers
Accessories: Uniquely keyed in-column key switch; forward & reverse selector; multi-functional clear view display w/BDI; speedometer; horn; reverse warning alarm; hour meter; cup holders; storage compartments; comfort grip steering wheel; Automotive lighting package; windshield; mirrors; hard top roof; reflectors; dual DC/DC converters; 2-pt seat belts
Frame: High-strength steel channel rail “ladder-style” frame, electrostatically powder coated
Steering: Adaptive electric power steering
Brakes: 4 Wheel hydraulic, front discs, rear drums, automatic parking brake
Suspension: Front: Double A-arm, independent coil spring over shock absorbers | Rear: Trailing link with Panhard bar, independent coil spring over shock absorbers
Tires: 205/65-10 10-ply DOT-rated tire
| UTILITRUCK | 2X | 2XL | 4X |
|---|---|---|---|
| Step Height: | 12.5 in. | ||
| Load Bed Height: | 26 in. | 26 in. | |
| Ground Clearance: | 7.5 in. | ||
| UTILITRUCK | UTILITRUCK LSV | |
|---|---|---|
| Max Speed Forward: | 19 MPH | 25 MPH |
| Range: | Up to 40 miles | |
| UTILITRUCK | 2X | 2XL | 4X |
|---|---|---|---|
| Vehicle Weight: | 1,500 lbs. | 1,650 lbs. | 1,750 lbs. |
| Rated Capacity: | 1,000 lbs. | 1,500 lbs. | |
| LSV Rated Capacity: | 1,000 lbs. |
1,250 lbs.
|
1,150 lbs.
|
|
Towing Capacity:
|
1,500 lbs.
|
||
| Horsepower: | 19 HP |
|---|---|
| Batteries: | Eight, 6 volts, 232 amp hour, 122 minutes, deep cycle |
| Charger: | On-board, micro-processor controlled, fully sealed, global, 100-230 VAC, 50/60 HZ |
| Controller Type: | Programmable, solid state, reduced speed reverse with diagnostic LED & calibrator interface |
| Controller Rating: | 450 amp |
| Motor Braking Mode: | Regenerative and pedal proportional braking with top speed limiting |
| Directional Control: | Fingertip directional control selection |
|
Drive Unit/Differential:
|
Direct drive, automotive differential, 16.67:1 drive ratio LSV: Direct drive, automotive differential, 12.62:1 drive ratio |
| Passenger Capacity: | Two, with up to four (2nd row seat) |
|---|---|
| Seating: | Adjustable driver seat, fixed passenger seat, covered in marine grade vinyl with armrests |
| Body: | Front: Rhino-Tuff™ molded polymer | Mid/Rear: Aluminum |
| Lighting: | Dual high/low beam headlights, taillights, brake lights, self-canceling turn signals; emergency flashers |
| Accessories: | Uniquely keyed in-column keyswitch; forward & reverse selector; multi-functional clear view display w/BDI; speedometer; horn; reverse warning alarm; hour meter; cup holders; storage compartments; comfort grip steering wheel; Automotive lighting package; windshield; mirrors; hard top roof; reflectors; dual DC/DC converters; 2-pt seat belts |
| Frame: | High-strength steel channel rail “ladder-style” frame, electrostatically powder coated |
|---|---|
| Steering: | Adaptive electric power steering |
| Brakes: | 4 Wheel hydraulic, front discs, rear drums, automatic parking brake |
| Suspension: | Front: Double A-arm, independent coil spring over shock absorbers | Rear: Trailing link with Panhard bar, independent coil spring over shock absorbers |
| Tires: | 205/65-10 10-ply DOT-rated tire |
Contact our team to learn more about the Utilitruck.
